Description
The M5-0.8 Socket Head Cap Screw is a medium-duty metric fastener designed for precise, compact assemblies requiring high torque control and durable fastening. Its cylindrical head with internal hex drive allows for streamlined installation in counterbored holes, making it ideal for mechanical systems, equipment housings, and compact structural assemblies.
Specifications
-
Thread Size: M5 × 0.8 (ISO Metric Coarse)
-
Head Type: Cylindrical socket head with internal hex drive
-
Drive Type: Hex socket (Allen)
-
Length: Commonly available from 8mm to 60mm in standard metric lengths
-
Material: High-strength alloy steel; also available in stainless steel, brass, and coated finishes
-
Finish Options: Black oxide, plain, zinc-plated, or stainless steel
-
Property Class: Typically Class 12.9 (for alloy steel) or A2/A4 stainless steel for corrosion resistance
Key Features
-
Mid-Size Strength: Balances compact size with reliable tensile strength, suitable for moderately stressed joints and medium-scale assemblies.
-
Standard Coarse Thread: The 0.8mm pitch ensures solid engagement and resistance to loosening from vibration or load cycling.
-
Precision Drive Control: Internal hex socket head enables accurate torque application and efficient space usage.
-
Multiple Finish Options: Offered in corrosion-resistant finishes for compatibility with harsh environments or aesthetic requirements.
-
Versatile Compatibility: Ideal for applications where M4 is too small and M6 too large, offering flexible fit in mechanical and electronic systems.
Typical Applications
The M5-0.8 Socket Head Cap Screw is commonly used in:
-
Electronics and Control Panel Assemblies
-
Small Machinery, Automation, and Robotics
-
Light Structural Frames and Fixtures
-
Automotive Engine Components and Mounting Brackets
-
Equipment Casings and Fastening Panels
-
Office Equipment, 3D Printers, and Consumer Devices
