Description
The M16-2.0 Socket Head Cap Screw is a high-strength, precision-engineered metric fastener designed for applications requiring superior clamping force, precise alignment, and reliable torque transfer. With its cylindrical socket head and internal hex drive, this screw allows for flush mounting in counterbored holes, making it ideal for high-load structural, mechanical, and industrial installations.
Specifications
-
Thread Size: M16 × 2.0 (ISO Metric Coarse)
-
Head Type: Cylindrical socket head with internal hex drive
-
Drive Type: Hex socket (Allen)
-
Length: Available in standard metric lengths (typically from 30mm to 150mm+)
-
Material: High-strength alloy steel; also available in stainless steel, black oxide, or zinc-plated finishes
-
Finish Options: Black oxide, plain, zinc-plated, or stainless
-
Property Class: Typically Class 12.9 (for alloy steel) or A2/A4 stainless steel for corrosion resistance
Key Features
-
Robust Strength with Compact Head: Offers a low-profile cylindrical head combined with high tensile strength—perfect for load-intensive and limited-clearance environments.
-
ISO Coarse Thread Profile: The 2.0mm pitch ensures strong engagement, reduced thread stripping, and better performance under vibration or dynamic loads.
-
Precision Torque Control: The hex socket drive enables consistent torque application with reduced risk of cam-out or damage.
-
Corrosion-Resistant Finishes: Options such as stainless steel or protective coatings make the screw suitable for outdoor, marine, or chemical-rich settings.
-
Heavy-Duty Versatility: Balances high load-bearing capacity with ease of installation and flush-mount compatibility.
Typical Applications
The M16-2.0 Socket Head Cap Screw is optimized for large-scale and heavy-duty applications across industries, such as:
-
Industrial Machinery and Mechanical Assemblies
-
Structural Steel Fabrication and Framing
-
Heavy Equipment and Agricultural Implements
-
Tooling Systems, Molds, and Precision Fixtures
-
Infrastructure Projects and Construction Frameworks
-
High-Stress Bolted Joints in Off-Road and Mining Equipment
